Label 1	Label 2
Make / Model	Perkins / 2806A-E18TAG2
Cylinder / Arrangement	6 / Vertical In line
Displacement	18,13 L
Bore and Stroke	145 mm x 183 mm
Compression Ratio	14.5 : 1
Rated Prime KWe	520
Rated RPM	1500rpm
Frequency Regulation, Steady State	± 1 %
Governor	Electrical
ENGINE DATA (CONT'D)
Exhaust Gas Flow	37 m3/ min
Exhaust Temperature	555 C
Max Allowable Back Pressure	6 kPa
Fuel Consumption 100% of Prime Rating	132 L/hr
Total Oil Capacity w/ Filters	62 L
Engine Air Flow	106 m3/min
Radiator and Engine Water Capacity	61 L
Max Water Temperature	103 C
GENERATOR DATA
Make	Stamford / Leroy Somer
Number of Phase	3
Cos Phi	0.8
Pole	4
Coupling	Single Bearing
Exciter Type	Brushless
Insulation Class / Temperature Rise	H / H
IP Rating	IP23
AVR	Included
CONTROL PANEL
Make	Deep Sea/ ComAp/ Similar
Engine Parameters	Oil Pressure, Water Temperature, RPM
Generator Parameters	Frequency, Voltage, Ampere, Cos Phi
Protection	Low Oil Pressure, High Water Temperature, Over-Under Speed,
0	Over-Under Frequency, Over-Under Voltage, Over Current
Other Features	Emergency Stop, Hour Counter, AMF

* Due to continuous product improvements, specifications might change without prior notice
** For best results, please contact your nearest PRIME® Generating Set dealer for consultations
