Label 1	Label 2
Make / Model	Perkins / 1103A-33G
Cylinder / Arrangement	3 / Inline
Displacement	3.3 L
Bore and Stroke	105 mm x 127 mm
Compression Ratio	19.25 : 1
Rated Prime KWe	24
Rated RPM	1500 RPM
Frequency Regulation, Steady State	± 5 %
Governor	Mechanical
ENGINE DATA (CONT'D)
Exhaust Gas Flow	5.8 m3/ min
Exhaust Temperature	520 0C
Max Allowable Back Pressure	8 kPa
Fuel Consumption 100% of Prime Rating	7.1 L / h
Total Oil Capacity w/ Filters	8.3 L
Engine Air Flow	2.15 m3/ min
Radiator and Engine Water Capacity	10.2 L
Max Water Temperature	110 0C
GENERATOR DATA
Make	Stamford / Leroy Somer
Number of Phase	3
Cos Phi	0.8
Pole	4
Coupling	Single Bearing
Exciter Type	Brushless
Insulation Class / Temperature Rise	H / H
IP Rating	IP23
AVR	Included
CONTROL PANEL
Make	Deep Sea/ ComAp/ Similar
Engine Parameters	Oil Pressure, Water Temperature, RPM
Generator Parameters	Frequency, Voltage, Ampere, Cos Phi
Protection	Low Oil Pressure, High Water Temperature, Over-Under Speed,
0	Over-Under Frequency, Over-Under Voltage, Over Current
Other Features	Emergency Stop, Hour Counter, AMF

* Due to continuous product improvements, specifications might change without prior notice
** For best results, please contact your nearest PRIME® Generating Set dealer for consultations
