PR300P
Diesel Generating Set
300KVA / 50Hz / 1500 rpm
ENGINE DATA
Label 1Label 2
Make / ModelCummins / NTA855-G1A
Cylinder / Arrangement6 / Inline
Displacement14 L
Bore and Stroke140 mm x 150 mm
Compression Ratio14.5 : 1
Rated Prime KWe240
Rated RPM1500 RPM
Frequency Regulation, Steady State≤1%
GovernorElectronic Speed Control w/ Actuator
ENGINE DATA (CONT'D)
Exhaust Gas Flow936 L/s
Exhaust Temperature498 °C
Max Allowable Back Pressure10 kPa
Fuel Consumption 100% of Prime Rating61.3 L/h
Total Oil Capacity w/ Filters38.6 L
Engine Air Flow379 L/s
Radiator and Engine Water Capacity 61 L
Max Water Temperature 103 °C
GENERATOR DATA
MakeStamford / Leroy Somer
Number of Phase3
Cos Phi0.8
Pole4
CouplingSingle Bearing
Exciter TypeBrushless
Insulation Class / Temperature RiseH / H
IP RatingIP23
AVRIncluded
CONTROL PANEL
MakeDeep Sea/ ComAp/ Similar
Engine ParametersOil Pressure, Water Temperature, RPM
Generator ParametersFrequency, Voltage, Ampere, Cos Phi
ProtectionLow Oil Pressure, High Water Temperature, Over-Under Speed,
0Over-Under Frequency, Over-Under Voltage, Over Current
Other FeaturesEmergency Stop, Hour Counter, AMF
* Due to continuous product improvements, specifications might change without prior notice
** For best results, please contact your nearest PRIME® Generating Set dealer for consultations
