Label 1	Label 2
Make / Model	Perkins / 2206C-E13TAG2
Cylinder / Arrangement	6 / Inline
Displacement	12.5L
Bore and Stroke	130 mm x 157mm
Compression Ratio	16.3 : 1
Rated Prime KWe	280
Rated RPM	1500rpm
Frequency Regulation, Steady State	± 1 %
Governor	ECM
ENGINE DATA (CONT'D)
Exhaust Gas Flow	64.8 m3/ min
Exhaust Temperature	630 C
Max Allowable Back Pressure	10.0 kPa
Fuel Consumption 100% of Prime Rating	71 L / h
Total Oil Capacity w/ Filters	40 L
Engine Air Flow	23.6 m3/ min
Radiator and Engine Water Capacity	31.4 L
Max Water Temperature	104 0
GENERATOR DATA
Make	Stamford / Leroy Somer
Number of Phase	3
Cos Phi	0.8
Pole	4
Coupling	Single Bearing
Exciter Type	Brushless
Insulation Class / Temperature Rise	H / H
IP Rating	IP23
AVR	Included
CONTROL PANEL
Make	Deep Sea/ ComAp/ Similar
Engine Parameters	Oil Pressure, Water Temperature, RPM
Generator Parameters	Frequency, Voltage, Ampere, Cos Phi
Protection	Low Oil Pressure, High Water Temperature, Over-Under Speed,
0	Over-Under Frequency, Over-Under Voltage, Over Current
Other Features	Emergency Stop, Hour Counter, AMF

* Due to continuous product improvements, specifications might change without prior notice
** For best results, please contact your nearest PRIME® Generating Set dealer for consultations
