Label 1	Label 2
Make / Model	Volvo Penta / TAD1342GE
Cylinder / Arrangement	6 / Inline
Displacement	12.78 L
Bore and Stroke	131 mm x 158 mm
Compression Ratio	18.1 : 1
Rated Prime KWe	280
Rated RPM	1500 RPM
Frequency Regulation, Steady State	≤1%
Governor	Electronic
ENGINE DATA (CONT'D)
Exhaust Gas Flow	33.0 m3/min
Exhaust Temperature	395 °C
Max Allowable Back Pressure	10 kPa
Fuel Consumption 100% of Prime Rating	69.3 L/ H
Total Oil Capacity w/ Filters	36 L
Engine Air Flow	869 cfm
Radiator and Engine Water Capacity	48 L
Max Water Temperature	103 °C
GENERATOR DATA
Make
Number of Phase	Stamford / Leroy Somer
Cos Phi	3
Pole	0.8
Coupling	4
Exciter Type	Single Bearing
Insulation Class / Temperature Rise	Brushless
IP Rating	H / H
AVR	IP23
CONTROL PANEL
Make	Deep Sea/ ComAp/ Similar
Engine Parameters	Oil Pressure, Water Temperature, RPM
Generator Parameters	Frequency, Voltage, Ampere, Cos Phi
Protection	Low Oil Pressure, High Water Temperature, Over-Under Speed,
0	Over-Under Frequency, Over-Under Voltage, Over Current
Other Features	Emergency Stop, Hour Counter, AMF

* Due to continuous product improvements, specifications might change without prior notice
** For best results, please contact your nearest PRIME® Generating Set dealer for consultations
