Label 1	Label 2
Make / Model	Perkins / 4016-61TRG3
Cylinder / Arrangement	16 / In line
Displacement	61.123L
Bore and Stroke	160 mm x 190 mm
Compression Ratio	13 : 1
Rated Prime KWe	1800
Rated RPM	1500
Frequency Regulation, Steady State	± 0.25 %
Governor	Electrical
ENGINE DATA (CONT'D)
Exhaust Gas Flow	490 m3/min
Exhaust Temperature	475 C
Max Allowable Back Pressure	3 kPa
Fuel Consumption 100% of Prime Rating	473 L/
Total Oil Capacity w/ Filters	214 L
Engine Air Flow	160 m3/min
Radiator and Engine Water Capacity	395 L
Max Water Temperature	98 C
GENERATOR DATA
Make	Stamford / Leroy Somer
Number of Phase	3
Cos Phi	0.8
Pole	4
Coupling	Single Bearing
Exciter Type	Brushless
Insulation Class / Temperature Rise	H / H
IP Rating	IP23
AVR	Included
CONTROL PANEL
Make	Deep Sea/ ComAp/ Similar
Engine Parameters	Oil Pressure, Water Temperature, RPM
Generator Parameters	Frequency, Voltage, Ampere, Cos Phi
Protection	Low Oil Pressure, High Water Temperature, Over-Under Speed,
0	Over-Under Frequency, Over-Under Voltage, Over Current
Other Features	Emergency Stop, Hour Counter, AMF

* Due to continuous product improvements, specifications might change without prior notice
** For best results, please contact your nearest PRIME® Generating Set dealer for consultations
