PR20SG
Diesel Generating Set
20KVA / 50Hz / 1500 rpm
ENGINE DATA
| Label 1 | Label 2 |
|---|---|
| Engine type | SG20K |
| Alternator Type | SG184ES |
| Air Intake Mode | Normally Aspirated |
| Way of Burning | Direct Injection |
| Cylinder | 4 |
| Bore*Stroke (mm) | 88 * 95 |
| Displacement (L) | 2.31 |
| Main power (kW) | 20 |
| Calibration Speed (r / m * in) | 1500 |
| Highest No-Load Speed | <= 1575 |
| Lowest No-Load Speed (r / m * in] | <= 650 |
| Fuel Consumption Rate ( g / k * W .h\) | <= 240 |
| Crankshaft Rotating | Anticlockwise |
| Cooling Method | Forced Water Cooling |
| Lubricating method | Pressure splash composite |
| Starting method | Electric start |
| Starting Voltage (12VDC/24 VDC) | 12V |
| Battery Recommended | 80A*1 |
| Net mass (kg) | 215 |
| cylinder working sequence | 1-3-4-2 |
| Exhaust temp. after turbing (C) | ≤600 |
| Intake pipe diameter (mm) | 50 |
| Oil sump capacity(L) | 7 |
| Number of teeth | 115 |
| Water tank capacity (L) | 6 |
| Cooling capacity in diesel engine(L) | 2 |
| Dimension (mm] LWH | 870 * 560 * 855 |
** For best results, please contact your nearest PRIME® Generating Set dealer for consultations
