Label 1	Label 2
Make / Model	G1BF4M1013EC
Cylinder / Arrangement	4 Cylinders / Inline
Displacement	4.8 L
Bore and Stroke	108 mm x 130 mm
Compression Ratio	19 : 1
Rated Prime KWe	61 kW
Rated RPM	1500 RPM
Frequency Regulation, Steady State	≤ 5%
Governor	Mechanical governor
ENGINE DATA (CONT'D)
Exhaust Gas Flow	18.37 m³/min
Exhaust Temperature	560°C
Max Allowable Back Pressure	3 kPa
Fuel Consumption 100% of Prime Rating	25.8 (PRP), 27.3 (LTP)
Total Oil Capacity w/ Filters	11
Engine Air Flow	6.08 m³/min
Radiator and Engine Water Capacity	19.7 L
Max Water Temperature	105 °C
GENERATOR DATA
Make	Stamford / Leroy Somer
Number of Phase	3
Cos Phi	0.8
Pole	4
Coupling	Single Bearing
Exciter Type	Brushless
Insulation Class / Temperature Rise	H / H
IP Rating	IP23
AVR	Included
CONTROL PANEL
Make	Deep Sea/ ComAp/ Similar
Engine Parameters	Oil Pressure, Water Temperature, RPM
Generator Parameters	Frequency, Voltage, Ampere, Cos Phi
Protection	Low Oil Pressure, High Water Temperature, Over-Under Speed,
0	Over-Under Frequency, Over-Under Voltage, Over Current
Other Features	Emergency Stop, Hour Counter, AMF

* Due to continuous product improvements, specifications might change without prior notice
** For best results, please contact your nearest PRIME® Generating Set dealer for consultations
