Label 1	Label 2
Make / Model	Cummins /KTA50-G8
Cylinder / Arrangement	16
Displacement	50.3
Bore and Stroke	159mm x 159 mm
Compression Ratio	14.9:1
Rated Prime KWe	1200
Rated RPM	1500 RPM
Frequency Regulation, Steady State	≤0.25%
Governor	Electronic / A1 Electrical
ENGINE DATA (CONT'D)
Exhaust Gas Flow	4.350 L/s
Exhaust Temperature	510 °C
Max Allowable Back Pressure	10,2 kPa
Fuel Consumption 100% of Prime Rating	289 l/hr
Total Oil Capacity w/ Filters	135 L
Engine Air Flow	21.7 m3/s
Radiator and Engine Water Capacity	210 Litres
Max Water Temperature	82-94 °C
GENERATOR DATA
Make	Stamford / Leroy Somer
Number of Phase	3
Cos Phi	0.8
Pole	4
Coupling	Single Bearing
Exciter Type	Brushless
Insulation Class / Temperature Rise	H / H
IP Rating	IP23
AVR	Included
CONTROL PANEL
Make	Deep Sea/ ComAp/ Similar
Engine Parameters	Oil Pressure, Water Temperature, RPM
Generator Parameters	Frequency, Voltage, Ampere, Cos Phi
Protection	Low Oil Pressure, High Water Temperature, Over-Under Speed,
0	Over-Under Frequency, Over-Under Voltage, Over Current
Other Features	Emergency Stop, Hour Counter, AMF

* Due to continuous product improvements, specifications might change without prior notice
** For best results, please contact your nearest PRIME® Generating Set dealer for consultations
